MidNite Solar MNEPV15-300 DIN Mount 15A Circuit Breaker

Hover over image to zoom

  • MNEPV15-300
MidNite Solar
MSRP: $47.00
$39.99 (You save $7.01)
SKU: ALG-053-03115
Condition: New
Weight: 1.00 LBS
Shipping: Calculated at checkout

 Product Description

Midnite 15A Circuit Breaker - MNEPV15-300

Midnite Solar, Circuit Breaker, DIN Mount, 15A, 300VDC, 1-Pole, 1.0" Wide, MNEPV15-300

MNEPV breakers are the same as CBI QY breakers except the standard used is inadequate for the solar industry. MidNite breakers have been evaluated by ETL to 300VDC and are listed for US and Canada. All of the NRTL listings still apply. Breakers ordered under the CBI part numbering system will not be listed for 300VDC and in many cases are not suitable for the solar industry.

DIN-mount breakers fit MidNite Solar and Magnum Energy enclosures, and MidNite Solar and OutBack Power PV array combiners. These breakers are polarized, so the positive wire from the power source needs to be connected to the "+" side of the breaker. The maximum PV array voltage must not exceed the voltage rating of the breakers used. The 600 VDC breakers also have a remote-trip actuator, useful for rapid shutdown.

Features

  • Highlights - 15A. 300VDC din rail mount breaker. 10,000 AIC. Breaker Torque Value: 20 In-Lbs (2.3NM).



General Information
Manufacturer: Midnite Solar
Product Line:
MN Series
Model ID:
MNEPV15-300
Certifications and Safety Ratings: etl.jpg



Mechanical Data

Technology: Circuit Breaker
Dimensions:
3.75 x 0.50 x 3.50 inches
Weight: 1.00 lbs
Type: DIN Mount
Rated DC Power: 300VDC
