Panasonic VBHN330SA16 330w Mono Solar Panel

Panasonic, 330W PV Module, MC4, PV Wire, 35mm Black Frame on White backsheet, BOW, 96 cell HIT, 15A Fuse, 600VDC, 311.3W PTC, VBHN330SA16

With the new VBHN325SA16, Panasonic re-established its position among leading solar Module manufacturers. Panasonic employs strict materials selection and qualified manufacturing processes. A vertically integrated factory allows for exhaustive quality assessments at every step of production. The resulting modules are IEC certified by JET. Panasonic photovoltaic modules HIT® feature an innovative hetero-junction cell structure made of mono-crystalline and amorphous silicon layers. Ultra-thin amorphous silicon layers prevent recombinations of electrons, keeping carrier loss to an absolute minimum. As a result, HIT conversion efficiency ratings are among the highest available today.

Employing 96 cells in the same size footprint, N330 and N325 HIT produce up to 36% more free electricity compared to conventional 60-cell panels.

Features

• Efficiency & Reliability - Protection from carrier recombination loss, optical absorption loss, and resistance loss. Reducing electrical loss between the cell fingers and tabs. Making the tab width thinner to expanded the light receiving surface. HIT Power solar panels are leaders in sunlight conversion efficiency. Obtain maximum power within a fixed amount of space. Save money using fewer system attachments and racking materials, and reduce costs by spending less time installing per watt. As temperatures rise, HIT Power solar panels produce 10% or more electricity (kWh) than conventional crystalline silicon solar panels at the same temperature.

• Power & Technology - Reducing reflection and scattering of incoming light. Improving generated electricity levels in morning and evening times. 240 Watts Output. Cell Efficiency 19.7%. Module Efficiency 21.76%. Black Frame. The power ratings for HIT Power panels guarantee customers receive 100% of the nameplate rated power (or more) at the time of purchase, enabling owners to generate more kWh per rated watt, quicken investments returns, and help realize complete customer satisfaction.


• Performance & Quality - The packing density of the panels reduces transportation, fuel, and storage costs per installed watt. Our silicon wafers located inside HIT solar panels are made in Oregon, and the panels are assembled in an IS0 9001 (quality), 14001 (environment), and 18001 (safety) certified factory. Unique eco-packing minimizes cardboard waste at the job site. The panels have a Limited 20-Year Power Output and 10-Year Product Workmanship Warranty.
