Morningstar MSC MeterBus Adapter

Morningstar, MeterBus adapter, MSC

Morningstar’s PC Meterbus Adapter (MSC) converts a controller’s meter port (RJ-11 phone type connector) to a standard RS-232 serial connector for connection to a PC or other equipment. The MSC may be used with any Morningstar controller or inverter equipped with a meter connection that does not also already have a RS-232 port.

Features

• Communications - A PC running Morningstar's MS View software or any other compatible software. A serial enabled device such as an internet gateway. Another MODBUS enabled hardware device at the site that needs to access solar system information.

• Monitoring - Battery voltage (including minimum and maximum). Solar charge current to the battery. Load current from the battery. Accumulated solar and load amp hours. Charge stage. Errors and alarms. Local and battery temperature. Data logging files.

• Includes - PC Meterbus adapter, RS-232 able with connectors (5.9'). RJ-11 cable with connectors (3.3').
