MidNite Solar MNEPV60 DIN Mount 60A Circuit Breaker
Hover over image to zoom
Product Description
| Midnite Solar 60A Circuit Breaker - MNEPV60 |
|
Midnite Solar, 60A 150VDC 1-Pole DIN Mount Circuit Breaker, MNEPV60 150VDC din rail mount breaker (13mm wide). DIN-mount breakers fit MidNite Solar and Magnum Energy enclosures, and MidNite Solar and OutBack Power PV array combiners. These breakers are polarized, so the positive wire from the power source needs to be connected to the "+" side of the breaker. The maximum PV array voltage must not exceed the voltage rating of the breakers used. The 600 VDC breakers also have a remote-trip actuator, useful for rapid shutdown. |
|
Features
|
| General Information | |
| Manufacturer: | Midnite Solar |
| Product Line: |
MN Series |
| Model ID: |
MNEPV60 |
| Certifications and Safety Ratings: |  |
| Mechanical Data |
|
| Technology: | Circuit Breaker |
| Dimensions: |
3.50 x 3.00 x 0.50 inches |
| Weight: | 0.25 lbs |
| Wire Size Range: | 6, and 14 AWG |
| DC Voltage Rating: | 150VDC |
| Number of Poles: | 1 |
| Current Rating: | 60 Amps |
| Terms & Conditions |
|
| Shipping: | Shipping Policy |
| Returns: | Returns Policy |
| Payments: | We accept: Visa, MasterCard, Discover, and American Express. We also accept checks, direct deposit and wire transfers for large orders. |
