EG4 EG448V314AIDWMB 16.0kWh 314Ah 51.2V Wallmount Indoor Lithium Battery

EG4 EG448V314AIDWMB 16.0kWh 314Ah 51.2V Wallmount Indoor Lithium Battery - EG448V314AIDWMB

EG4, Wallmount Indoor 314Ah Lithium Battery, 16.0kWh Storage Capacity, 51.2V, 200A Continuous Output, Third-Generation BMS, RS485, CAN, Self-Heating Function, IP20, 10 Year Warranty, EG448V314AIDWMB

The EG4® WallMount 314Ah Indoor battery delivers dependable, high-efficiency storage for clean, protected spaces. Each unit uses advanced lithium iron phosphate cells and provides about 16kWh of energy. The form factor stays compact and familiar, sized to fit where earlier models fit, which keeps retrofits and system expansions straightfoward. This model includes EG4’s smart BMS with active balancing, network connectivity, and over the air firmware updates. Installers and homeowners get faster setup, stronger control, and long-term performance support through the EG4 battery monitoring app.

Features

Longer Cell Life
Active balancing (2 – 3A) speeds up cell equalization for longer life and consistent performance across paralleled units.

Auto Configuration
Eliminates Manual Dip Switch Setup, Detects and Configures Automatically for Faster Commissioning.

Multiple Compatible Inverters
Smart Bms Communicates with Multiple Inverter Protocols for True Plug-And-Play Operation.

Configurable Ports
No/nc + 12 v Outputs for Generator Start, Alarms, or Custom Triggers.

Enhanced Safety
Internal Fire Arrestors, Reinforced Cell Enclosures, and Compliance with The Latest Ul and Ahj Standards.
