EG4 EG4CV48V100AV3 Chargeverter GC 48Vdc Battery Charger

EG4 EG4CV48V100AV3 Chargeverter GC 48Vdc Battery Charger - EG4CV48V100AV3

EG4, Chargeverter 48Vdc Battery Charger, Deliver up to 100Adc/5120 Watts with 240Vac Input, EG4CV48V100AV3

The EG4 Chargeverter-GC is a powerful 48V battery charger capable of rapidly charging at 100 amps, or more than 5000 watts, significantly faster than traditional chargers.

The EG4 Chargeverter GC is a powerful and efficient 48V battery charger, built to deliver up to 100A, with a 5120W output. Capable of charging a 5kWh battery in approximately one hour, this advanced charger ensures fast, reliable power delivery to any battery system, and features adjustable charge parameters so you can optimize output for your batteries.

The Chargeverter GC was built with safety and longevity in mind, and not only features a built-in circuit breaker for failsafe protection during operation, but this charger is also protected against unstable sine waves from lower-quality generators, helping to protect system components and guarantee consistent delivery.

Designed for seamless integration with EG4 components, the Chargeverter GC features full closed-loop communications, allowing it to charge intelligently based on the battery’s state of charge. This feature optimizes system efficiency and prolongs battery life, making it an essential component for any serious power storage system. Ensure you’re always powered and prepared with the Chargeverter GC from EG4!

Features

120VAC/208VAC/240VAC Input Capability

Optimized for 240VAC power supplies for maximum output. 120VAC or 208VAC input can be used with an optional adapter plug.

RS485 Communications Port

An RS485 port on the side of the Chargeverter-GC allows the user to establish closed-loop communication between the charger and battery. This facilitates the exchange of SOC information for user-defined charging thresholds. Without closed-loop communication (SOC information), the charger uses battery voltage for user-defined charging thresholds.

Built-In Breaker

The unit has a built-in breaker to quickly shut off the charger output for added safety and protection.

Optimized for Generator Use

Plug the Chargeverter-GC directly into a generator to charge batteries without concern for generator power quality issues, commonly referred to as “dirty power.” Connect the automatic generator start circuit to the Chargeverter-GC dry contacts to allow the generator to charge the battery bank at preset start/stop voltages or SOC thresholds.
