OutBack SmartHarvest SCCM20-100 MPPT Charge Controller

SCCM20-100

Hover over image to zoom

  • SCCM20-100
OutBack Power
Unavailable
SKU: SLR-520-0155
Note: Out of Stock
Condition: New
Weight: 2.16 LBS

 Product Description

OutBack Power 100VDC 20A MPPT Charge Controller -  SmartHarvest sccm20-100

Outback, SmartHarvest MPPT Charge Controller, 20A, 100VDC, with Load Control, SCCM20-100

SmartHarvest's mission is to make the advanced technologies usually associated with premium PV energy systems available to users regardless of their system sizes or budgets.  The SCCM10-100 accomplishes this goal by placing MPPT charge controller capability within the reach of a much wider application base, ensuring higher system yeilds at the power and size levels where that advantage can make the most difference.

By maximizing solar energy harvesting under a wider variety of environmental conditions, MPPT technology helps the system extract as much electricity as possible for more effective energy storage -- making the innovative SCCM10-100 ideal for use in efficiency-driven applications that can benefit from improved, advanced charger technology.

Features

  • Quality Meets Power - 20A/100V Maximum Power Point Tracking (MPPT) charge controller for off-grid and grid-connected PV Systems with energy storage.
  • Communicates & Stores Data Effectively - MPPT charge controller ensures maximum yield from available solar energy. Integrated LED display.
  • Efficient & Secure - Backed by OutBack Power's global sales and support network.



General Information
Manufacturer: OutBack Power
Product Line:
 SmartHarvest
Model ID:
 SCCM20-100
Certifications and Safety Ratings: ul.jpg csa.jpg etl.jpg



Mechanical Data

Technology: Maximum Power Point Tracking (MPPT)
Dimensions:
 4.30 x 7.80 x 2.20 inches
Weight: 2.16 lbs
Casing: (Black)
Charging Regulation: Four Stages: Bulk, Absorb, Float, & Equalize
Absorb Time: 2 Hours
Equalization Time: 1 Hour
Battery Type Selection: VRLA/Flooded Selectable Via Jumper. Factory Default VRLA (Jumper Inserted)
Data Logging: Internal Data Logging Up to One Week, Longer Data Logging Available with Monitoring Software.
Display: 3 LEDs
IP Class: IP20
Operating Temperature Range: -40°C to +60°C
Humidity: 0-95% RH Non-Condensing
Certifications: CE, IEC/EN 62109-1



Electrical Data

Maximum Output Current: 20
Nominal Battery Voltages: 12/24 Volts
Input Panel Power: 300/600
Bulk Voltage: Flooded: 14.8/29.6, VRLA: 14.6/29.2 VDC
Absorb Voltage: Flooded: 14.8/29.6, VRLA: 14.4/28.8 VDC
Float Voltage: Flooded: 13.2/26.4, VRLA: 13.5/27.0 VDC
Equalization Voltage (Flooded Battery): 15.5/31.0 VDC
State of Charge Low Voltage Disconnect: 11.4/22.8 Volts
Low Battery Load Reconnect: 12.4/24.8 VDC
High Battery Load Disconnect: 15.0/30.0 VDC
Temperature Compensation:
 -5mV/°C
Self-Consumption: 14/80 mA
Peak Efficiency: 97%



Datasheets

Document Type
logo-adobe-pdf-2.jpgOutBack SmartHarvest SCCM20-100 Specifications Specifications
logo-adobe-pdf-2.jpgOutBack SmartHarvest SCCM20-100 Manual Users Manual
Warranty 2 Year Limited Warranty
logo-adobe-pdf-2.jpgOutBack SmartHarvest SCCM20-100 Warranty Warranty
